Figure 9
From: High frequency resistive switching behavior of amorphous TiO2 and NiO
Extracted scattering parameters of the CPW-microstrip transition; S11 (red, as seen from CPW side), S22 (green, as seen from microstrip line side) and S21 (blue).
