Figure 2

From: The largest amber-preserved flower revisited

Figure 2

Details of Symplocos kowalewskii comb. nov. et emend. (Symplocaceae; X4088) from late Eocene Baltic amber. (a) Anther. (b) Basally fused and broadened filaments, arranged in three rows and forming a fused ring. (c) Underside of the fused staminate ring with trichomes (arrowhead). (d) Simple, long, acute trichome (right arrowhead), magnified from (c); left arrowhead indicates fungal hyphae. Scale bars 200 µm in (a), (b), (d); 1 mm in (c).
