Figure 8
From: The historical impact of anthropogenic air-borne sulphur on the Pleistocene rock art of Sulawesi
Time-lapse photography of active exfoliation ‘hot-spots’ at Leang Jarie. (a) Map showing proximity of the Leang Jarie cave site to rice cultivation, main road traffic and cement-based infrastructure. (b,c) Overview of inactive exfoliation and close-up of two active spall-scar patches on 8 October 2018. (d,e) As for (b,c) but on 30 June 2021. The area covered by the two patches within the yellow oval has almost doubled in ~ 2.5 years. Map image is for 16 August 2019 on Google Earth Pro 7.3.4.8573 (24 March 2022) at http://www.google.com/earth/index.html (accessed 1 May 2022). Photo credits: R. Lebe.
