Figure 5
From: Application of a CNN to the Boda Claystone Formation for high-level radioactive waste disposal
Examples of detected fractures that are barely visible to the naked eye (with ResNet‑152) in Section 1. Note: Image quality depends on necessary resampling (224 × 224 pixels), as described in the text. Based on PURAM data.
