Figure 7
The extraction rate of global yield obtained from Esquivel model with different particle size is fitted by Esquivel data at constant parameters (a) 10 MPa, 60 °C (b) 10 MPa 40 °C (c) 30 MPa 40 °C and (d) 30 MPa 60 °C.
