Figure 4
Specimens of Madakoala sp. cf. M. devisi and Nimiokoala sp. indet. from the Pwerte Marnte Marnte site, with annotated line drawings. Madakoala sp. cf. M. devisi: (a, b) partial right lower molar row preserving m1–m4 (NTM P12015); (c) left m3 talonid (NTM P12016); (d, e) paracone from right M 2? (NTM P12017); (f, g) left M1 (NTM P14005). Nimiokoala sp. indet.: (h, i) left protocone (NTM P12018); (j, k) right protoconid (NTM P12019). The orientation arrows (Anterior, Buccal) relate to the right lower molar (a, b, j, k), and left upper molar (f, g, h, i), specimens. end entoconid, hyd hypoconid, lc lingual cingulum, mcl metaconule, me metacone, med metaconid, ncd neomorphic cuspid, nmcl neometaconule, pa paracone, pacl paraconule, pc precingulum, popac postparacrista, popr postprotocrista, poprd postprotocristid, pr protocone, prd protoconid, prmec premetacrista, prprd preprotocristid, rpopac remnant postparacrista, rprmec remnant postmetacrista, rstA remnant stylar cusp A, stA Stylar cusp A, stB stylar cusp B, stD Stylar cusp D, stE stylar cusp E.
