Figure 4
Examples of unpublished unhealed cranial injuries documented in SJAPL in this study. (a–b) Blunt-force traumas in the right parietal bone of cranium C001(Z4). (c) Large blunt-force trauma affecting the right parietal and frontal bones of cranium C002. (d) Linear fractures in the right half of the frontal bone of cranium C003(B1). (e) Linear fracture above the nasion of cranium C130. (f) Large blunt-force trauma affecting both left and right parietal and the occipital bones of cranium C148. (g–h) Sharp-force trauma in the right parietal bone of cranium C168. (i) Blunt-force trauma in the left parietal bone of cranium C169. (j) Radiating linear fractures in the occipital bone of cranium C172. (k) Blunt-force trauma affecting the right parietal and occipital bones of cranium C189. (l) Blunt-force trauma in the right parietal bone and linear fractures affecting the occipital bone of cranium C198. (m–n) Blunt-force traumas in the left half of the frontal bone of cranium C199. (o–p) Large blunt-force traumas affecting both the right parietal and occipital bones of cranium C225. (q) Blunt-force trauma in the left parietal bone of cranium C229. (r–s) Blunt-force trauma and linear fractures affecting both the frontal and left parietal bones of cranium C326. (t) Sharp-force trauma in the occipital bone of cranium C334. Panels (a), (c–g), (i–m), (o–r), (t) in ectocranial view; panels (b), (h), (n), (s) in endocranial view.
