Figure 3
From: Chemically-stable flexible transparent electrode: gold-electrodeposited on embedded silver nanowires
FE-SEM images of: (a) PS-AgNW, (b) PS-AgNW@Au(1 s,1 V) (nucleation pulse in the gold plating process), (c) PS-AgNW@Au(20), (d) PS-AgNW@Au(40) and (e) PS-AgNW@Au(60) (f) PS-AgNW@Au(80).
