Figure 7
From: Comprehensive anatomical study of meningeal arteries in dromedaries
Rostral view of an exposed cranial cavity of a dromedary camel (brain removed), showing the branching patterns of the caudal meningeal arteries within the caudal cranial region. 1, Mastoid foramen; 2, first branch of caudal meningeal artery; 3, caudal meningeal artery; 4, rostral branches of caudal meningeal artery; 5, caudal branch of the right middle meningeal artery; 6, caudal radiating branches of caudal meningeal artery.
