From: Comparison of tibial fracture plate length, placement, and fibular integrity effects on plate integrity through finite element analysis

Figure 2

The location of all ligaments. (a) The MCL (b) The LCL (c) The proximal anterior tibiofibular ligament (d) The proximal posterior tibiofibular ligament (e) The distal anterior tibiofibular ligament (f) The distal posterior tibiofibular ligament (g) The interosseous membrane. All these ligaments are marked by round dotted circles. MCL, medial collateral ligament; LCL, lateral collateral ligament.
