Fig. 6
From: Sources of seismic noise in an open-pit mining environment
Amplitude versus time changes for the vertical component of station ST03 for the 10–40 Hz frequency band. Blue line: amplitude values every 30 min. Red: mean daily value between 8:00 and 18:00. Orange line: week-averaged value (8:00–18:00).
