Fig. 1

From: Simulation of three dimensional diffraction patterns as aid of structural analysis for complex epitaxial films

Fig. 1

For the PbTiO3/SmScO3(001) epitaxial film, (a) experimental 3D-RSM result and (b) slice at Qz = 4.75 Å−1 show the PTO 3hk diffraction spots. (c) Schematic epitaxy relationship of PTO film (100) plane on SSO substrate pseudo-cubic (001) plane and the corresponding (d) simulated 3D diffraction pattern for PTO and (e) its details. Please note that, the color indexed spots in (b, e) correspond to the same color PTO lattice illustrated in (c).
