Fig. 6 | Scientific Reports

Fig. 6

From: A comparative transcriptomic analysis provides insights into molecular mechanisms driving salt tolerance in soybean

Fig. 6

Heatmap illustrating the transcriptomic landscape of DEGs in the tolerant rice genotype al 24 h under salt stress and control conditions (TOLC-TOL24). DEGs were functionally categorized into major biological process categories including transporters, stress response, cell wall modification, carbohydrates, photosystems, lipid metabolism, and phytohormones & signaling. Expression values were calculated as TMM-normalized FPKM, and log2-transformed for visualization of expression changes across conditions. DEGs with a false discovery rate (FDR) ≤ 0.001 and a log2 fold change (log2FC) ≥ 2 were included. Please refer to the color scale bar for expression.
