Fig. 3
From: Nanoparticle delivery of combined plant extracts enhances immune response in immunocompromised rats
graphs display immunological parameters measured on days 14 and 28, including (a) Total leucocytic count, (b) Complement 3, (c) Complement 4, (d) Interferon gamma, and (e) Tumor necrosis factor. Data are shown as mean ± SE (n = 8) and analyzed with one-way ANOVA and Duncan test for group comparisons. A paired sample t-test was used to evaluate results within the same group between the two days. Significant differences are indicated by lowercase letters for day 14 and uppercase letters for day 28, along with symbols denoting differences between days: * for P ≤ 0.033, ** for P ≤ 0.002, and *** for P ≤ 0.001.
