Table 4 Tested scenarios and corresponding formulas.
From: Analysis of the CO2 adsorption on AC: experimentation and statistical studies
Model | Qa (g/g) |
|---|---|
Monolayer (Model 1) | \(Q_{a} = \frac{{n.D_{M} }}{{\left( {1 + \left( {\frac{{P_{1/2} }}{P}} \right)} \right)}}\) (1) |
Two layer with two energies (Model 2) | \(Q_{a} = n.D_{M} \frac{{\left( {\frac{p}{{P_{1} }}} \right)^{n} + 2.\left( {\frac{p}{{P_{2} }}} \right)^{2n} }}{{1 + \left( {\frac{p}{{P_{1} }}} \right)^{n} + \left( {\frac{p}{{P_{2} }}} \right)^{2n} }}\) (2) |
Multilayer model with saturation (Model 3) |
|
