Fig. 3

From: The effect of QPQ treatment on the wear and corrosion resistance of 42CrMo bearing steel

Fig. 3The alternative text for this image may have been generated using AI.

SEM images and EDS analysis of samples under different processing conditions: (a) 580 °C × 90 min, (b) EDS results at 580 °C × 90 min, (c) 580 °C × 120 min, (d) EDS results at 580 °C × 120 min, (e) 620 °C × 90 min, (f) EDS results at 620 °C × 90 min, (g) 620 °C × 120 min, and (h) EDS results at 580 °C × 90 min. Magnification: 500×.
