Fig. 11
From: Research on boost conversion of SiC-based laser power supply for aerospace applications
Experimental waveform. (a) Switching Device Gate Drive Waveform; (b) Boost Converter Coupled-Inductor Topology; (c) Load Transient Response Waveforms; (d) Output Voltage Step Response.
