Fig. 4: Fluorescent in situ hybridization (FISH) analysis of E. aerogenes and C. acetobutylicum mono-cultures on glucose and the consortium on glucose and cellobiose.
From: Biohydrogen production beyond the Thauer limit by precision design of artificial microbial consortia
The consortium comprised an inoculum ratio of 1:10,000 E. aerogenes: C. acetobutylicum. The phase-contrast images (a), FITC filter set images (b), TRITC filter set images (c) and images from overlay of FITC/TRITC filter sets (d) are shown at the time point where gas production was the highest (T4). The scale bar is 10 µm.
