Fig. 1: Crystal structure of 1. | Communications Materials

Fig. 1: Crystal structure of 1.

From: Light-driven anisotropy of 2D metal-organic framework single crystal for repeatable optical modulation

Fig. 1

Optical images of the single crystal of 1 in dark and bright fields. Scale bars, 50 μm (a) and 100 μm (b). c Secondary building unit of 1, adamantane fragments are omitted for clarity and (d) the layer of 1, viewed along the crystallographic axis b (hydrogen atoms and nitrate anions are omitted for clarity). Color code: gray—carbon, light-gray—hydrogen, blue—nitrogen, red—oxygen, orange—copper. e The structural transformation of 1 extracted from SCXRD analysis upon heating (see Supplementary Fig. S1). f In-situ PXRD patterns (CoKα radiation) recorded upon the heating of the powder of 1 from 298 to 338 K with 5 K step.
