Figure 6

From: Recent origin and semi-permeable species boundaries in the scleractinian coral genus Stylophora from the Red Sea

Figure 6

Variability of in-vivo colony appearance and skeleton morphology of Stylophora morphospecies from the Red Sea.

(A–D) S. mamillata SA432 and SA433, (E–H) S. wellsi SA371 and SA731, (I–T) “S. pistillata” complex: (I,J) S. danae SA730, (K,L) S. subseriata SA1500, (M,N) S. pistillata SA1743, (O,P) S. kuehlmanni SA1757, (Q,R) S. pistillata SA1546, showing verrucae typical of Pocillopora, (S,T) S. pistillata “mordax” form SA1241. Colours refer to S. mamillata (green), S. wellsi (blue), and “S. pistillata” complex (black). Scale bars 1 cm.
