ABL gene fuses BCR during t(20;22) results in Philadelphia-negative, but BCR/ABL-positive chronic myeloid leukemia

Leukemia volume 16, pages 951–952 (2002)Cite this article

Chronic myelogenous leukemia (CML) is usually characterized by the presence of the Philadelphia (Ph) translocation, t(9;22)(q34;q11). BCR-ABL fusion in Ph translocation is well known to be critical in the pathogenesis. The interest in treating this disease is now focused on a novel oncoprotein p210BCR-ABL as a target molecule. On the other hand, a minority of patients with CML have cytogenetically normal leukemic cells. A subgroup in Ph-negative patients showed a rearrangement of the major BCR.1 A previous report, analyzing patients with Ph-negative CML showed M-BCR rearrangement in 11 out of 23 patients.2 Insertion of a small segment of chromo- some 9 (9q34) into chromosome 22q11 was suggested to form M-BCR in Ph-negative CML.3,4 A unique complex translocation: t(9;12;15)(q34;q12;q21) in a CML patient has been reported to mask the Ph chromosome.5 Fluorescence in situ hybridization (FISH) has become useful to confirm cytogenetic diagnosis in Ph-positive and -negative CML.6 Seong et al,7 using hypermetaphase FISH, reported that two out of six Ph-negative CML patients had ABL insertions into the BCR gene on chromosome 22. In Ph-negative CML, retranslocation between chromosomes 9q+ and 22q− was postulated to result in normal-looking chromosomes 9 and 22.1 We here report a patient with t(20;22)(q13;q11) accompanying BCR-ABL fusion on chromosome 22 which resulted in a normal-looking cytogenetic study by the Giemsa-banding method.

Ph-negative and BCR-positive CML patients are now easily analyzed using molecular techniques. The finding of BCR-ABL molecular rearrangements indicates undetected Ph translocation in Ph-negative patients. Cytogenetic study in this patient failed to demonstrate Ph translocation. RT-PCR analysis indicated that this patient had BCR-ABL rearrangement. This finding was confirmed by dual-color FISH analysis demonstrating a BCR-ABL fusion signal on one chromosome 22. Meanwhile, karyotyping by SKY analysis demonstrated t(20;22) without abnormality in chromosome 9. These results indicate that only a small segment of chromosome 9 including ABL is located on chromosome 22. Inazawa et al1 speculated that retranslocation between chromosome 9 and 22 might result in Ph-negative CML. Other reports suggested insertion of a small segment of chromosome 9 into chromosome 22 to form M-BCR in Ph-negative CML.3,4 Moreover, masked Ph chromosomes in the literature usually have a 9q+ anomaly that inspires further examination of the translocated part on 9q34. However, the current case showed neither 9q+ nor 22q− anomaly using standard G- and Q-bandings.

This is a preview of subscription content, access via your institution

Access options

Buy this article

  • Purchase on SpringerLink
  • Instant access to the full article PDF.

USD 39.95

Prices may be subject to local taxes which are calculated during checkout

Figure 1

References

  1. Inazawa J, Nishigaki H, Takahira H, Nishimura J, Horiike S, Taniwaki M, Misawa S, Abe T . Rejoining between 9q+ and Philadelphia chromosomes results in normal-looking chromosomes 9 and 22 in Ph1-negative chronic myelocytic leukemia Hum Genet 1989 83: 115–118

    Article  CAS  Google Scholar

  2. Kantarjian HM, Shtalrid M, Kurzrock R, Blick MB, Dalton WT, LeMaistre A, Strass SA, McCredie KB, Gutterman J, Feireich EJ, Talpaz M . Significance and correlations of molecular analysis results in patients with Philadelphia chromosome-negative chronic myelogenous leukemia and chronic myelomonocytic leukemia Am J Med 1988 85: 639–644

    Article  CAS  Google Scholar

  3. Rassool F, Martiat P, Taj A, Klisak I, Goldman J . Interstitial insertion of varying amounts of ABL-containing genetic material into chromosome 22 in Ph-negative CML Leukemia 1990 4: 273–277

    CAS  PubMed  Google Scholar

  4. Nishigaki H, Misawa S, Inazawa J, Abe T . Absence in Ph-negative, M-BCR rearrangement-positive chronic myelogenous leukemia of linkage between 5′ ABL and 3′ M-BCR sequences in Philadelphia translocation Leukemia 1992 6: 385–392

    CAS  PubMed  Google Scholar

  5. Shanske AL, Grunwald H, Cook P, Heisterkamp N, Groffen J . Philadelphia-negative chronic myelogenous leukemia in a patient with a unique complex translocation: 46,XY,t(9;12;15)(q34;q12;q21) Leuk Res 1998 22: 645–648

    Article  CAS  Google Scholar

  6. Acar H, Stewart J, Connor MJ . Philadelphia chromosome in chronic myelogenous leukemia: confirmation of cytogenetic diagnosis in Ph positive and negative cases by fluorescence in situ hybridization Cancer Genet Cytogenet 1997 94: 75–78

    Article  CAS  Google Scholar

  7. Seong D, Kantarjian HM, Albitar M, Arlinghaus R, Xu J, Talpaz M, Rios MB, Qiang Guo J, O'Brien S, Siciliano M . Analysis of Philadelphia chromosome-negative BCR-ABL-positive chronic myelogenous leukemia by hypermetaphase fluorescence in situ hybridization Ann Oncol 1999 10: 955–959

    Article  CAS  Google Scholar

  8. Kawasaki ES, Clark SS, Coyne MY, Smith SD, Champlin R, Witte ON, McCormick FP . Diagnosis of chronic myeloid and acute lymphocytic leukemias by detection of leukemia-specific mRNA sequences amplified in vitro Proc Natl Acad Sci USA 1988 85: 5698–5702

    Article  CAS  Google Scholar

  9. Kakazu N, Kito K, Hitomi T, Oita J, Nishida K, Masuda K, Miki T, Abe T . Characterization of complex chromosomal abnormalities in B-cell lymphoma by a combined spectral karyotyping (SKY) analysis and fluorescence in situ hybridization (FISH) using a 14q telomere probe Am J Hematol 2000 65: 291–297

    Article  CAS  Google Scholar

Download references

Acknowledgements

The authors are indebted to Professor J Patrick Barron of the International Medical Communications Center of Tokyo Medical University for his review of this manuscript.
