Main

The neoplastic cells in non-Hodgkin's lymphoma and nodular lymphocyte predominant Hodgkin's lymphoma express B-cell-specific antigens, immunoglobulin mRNA transcripts, and their proteins.1 In contrast, Reed–Sternberg and Hodgkin's cells in classical Hodgkin's lymphoma, despite their rearranged immunoglobulin genes, fail to express functional immunoglobulin mRNA and/or protein, and lack B-cell-specific antigens in most instances.1, 2, 3, 4 It has been speculated that the lack of immunoglobulin mRNA transcripts and immunoglobulin protein expression, as well as B-cell specific antigens may be due to either crippling mutations of the immunoglobulin genes found in approximately 25% of cases,2, 5, 6, 7 or downregulation and disruption of the B-cell-specific transcription factors.8, 9, 10

Recent studies have shown that transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 are expressed in the majority of B-cell lymphomas and nodular lymphocyte predominant Hodgkin's lymphoma, but are downregulated in Reed–Sternberg and Hodgkin's cells of classical Hodgkin's lymphoma.1, 2, 3, 8, 9, 10 Most studies report that the Pax-5 is expressed in 100% of non-Hodgkin's lymphomas of B-lineage and a significant proportion of classical Hodgkin's lymphoma. However, there is inconsistency in the reported incidence of expression of the Oct-2, Oct-1, BOB.1, and PU.1 in classical Hodgkin's and non-Hodgkin's lymphomas in the literature.

To further characterize the expression profile of transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1, we performed immunohistochemistry on tissue microarray constructs consisting of 40 cases of classical Hodgkin's lymphoma, 11 nodular lymphocyte predominant Hodgkin's lymphoma, 10 follicular lymphoma, 14 diffuse large B-cell lymphoma, 11 mantle cell sell lymphoma, 9 small lymphocytic lymphoma, 3 marginal zone B-cell lymphoma, 9 anaplastic large cell lymphoma, and 2 precursor T-cell acute lymphoblastic lymphoma.

The neoplastic cells in all nodular lymphocyte predominant Hodgkin's lymphoma cases expressed the PU.1 whereas the Reed–Sternberg and Hodgkin's cells in all classical Hodgkin's lymphoma cases failed to express the PU.1. This finding confirms and further expands prior observations.1, 10, 11, 12, 13 In addition, the neoplastic cells in all nodular lymphocyte predominant Hodgkin's lymphoma cases consistently expressed the BOB.1. In contrast, only a minority of Reed–Sternberg and Hodgkin's cells in classical Hodgkin's lymphoma weakly expressed the BOB.1. All transcription factors were expressed in the majority of non-Hodgkin's lymphomas of B-lineage in this study. However, about 50% of the diffuse large B-cell lymphoma cases failed to express the transcription factor PU.1. The PU.1-negative cases included four CD30-positive anaplastic variant of diffuse large B-cell lymphoma.

Materials and methods

Pathological Specimens

From the files of the department of pathology at the University of Iowa Hospitals and Clinics, 109 cases were selected and representative paraffin embedded tissue blocks were retrieved for construction of tissue microarrays. The cases included 40 classical Hodgkin's lymphoma (22 mixed cellularity and 18 nodular sclerosis), 11 nodular lymphocyte predominant Hodgkin's lymphoma, 47 mature B-cell non-Hodgkin's lymphomas of different types, 9 anaplastic large cell lymphoma, and 2 precursor T-cell acute lymphoblastic lymphoma.

Tissue Microarray Constructs

Hematoxylin and eosin stained slides from all 109 cases were reviewed to localize precisely the target areas of the tumor in corresponding paraffin embedded tissue blocks for inclusion within the tissue microarray. The tissue microarray was made using a manually operated machine that uses two separate needles for punching the donor and recipient blocks (Beecher Instruments, Silver Spring, MD, USA). Tissue cylinders (0.6 mm in diameter) retrieved from the donor blocks were oriented within the recipient block using the instrument's X-Y micrometer adjustment knobs. Four cores from each donor block were punched and oriented into the recipient blocks. The completed recipient block was incubated at 37°C for 20 min to facilitate adhesion of the tissue cores to the paraffin.

Immunohistochemical Study

Sections of the tissue microarray blocks were mounted onto positively charged slide, baked at 56°C for 60 min, deparaffinized in xylene, rehydrated in graded alcohols, and rinsed. For heat-induced epitope retrieval, the tissue sections were placed in 10 mM citrate buffer at pH 6.0 (Pax-5, Oct-1, Oct-2, and BOB.1), or in ethylenediaminetetraacetic acid antigen retrieval solution at pH 8.0 (PU.1), and heated in a microwave oven for two cycles of 5 min each, or three cycles of 5 min each, respectively. After cooling the sections for 20 min at room temperature, endogenous peroxidase activity was blocked using hydrogen peroxide/methanol, and for the prevention of nonspecific background staining, blocking serum was applied (Santa Cruz staining kit). The sections were then incubated with the monoclonal antibodies to the Oct-1 (clone 12F11, Santa Cruz Biotechnology, Santa Cruz, CA, USA), the PU.1 (clone G148-74, Pharmingen, San Diego, CA, USA), the Pax-5 (clone 24, Transduction Laboratories, Lexington, KY, USA), and polyclonal antibodies to the Oct-2 and BOB.1 (Santa Cruz Biotechnology, Santa Cruz, CA, USA) at the following dilutions: 1:10 (Oct-1) and 1:50 (PU.1, Oct-2, Pax-5, BOB.1) for 30–60 min at room temperature. For the detection of bound primary antibodies either the streptavidin–biotin (LSAB-DAKO) or the EnVision technique (DakoCytomation; Carpinteria, CA, USA) with diaminobenzidine chromogen as a substrate was used. Sections of a tonsil with reactive lymphoid hyperplasia served as positive and negative controls.

Results

The results of expression profile of transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 in Hodgkin's and non-Hodgkin's lymphomas are summarized in Table 1.

Table 1 Expression of transcription factors Pax-5, Oct-2, Oct-1, BOB.1, and PU.1 in Hodgkin and non-Hodgkin's lymphomas
Full size table

Histopathologic Findings

Sections of the tissue microarray blocks were stained with hematoxylin and eosin and compared with routine sections from the original donor blocks to assure that adequate representative tumor cells were present for evaluation. Only cases that had at least two out of four tissue cores with adequate tumor were included in the study. Expression of the Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 was scored by counting the number of positive cells and the signal intensity. Positivity was defined as nuclear staining of at least 1/3 of the neoplastic cells and the intensity of staining was graded as low, moderate, and high. The occasional cytoplasmic staining seen with some antibodies was considered as nonspecific and considered as negative.

Immunohistochemical Findings

Pax-5 expression

In tonsil with reactive lymphoid hyperplasia, the Pax-5 was strongly expressed in lymphocytes residing in mantle zone. The Pax-5 was also expressed with weak to moderate intensity in germinal center cells (Figure 1). Virtually, all cases of Hodgkin's lymphoma of B-lineage demonstrated a moderate to strong nuclear staining for the Pax-5 (Figures 2 and 3), with the exception of one case of mantle cell lymphoma, which was completely negative. The neoplastic cells of nodular lymphocyte predominant Hodgkin's lymphoma showed positive nuclear staining with moderate intensity in more than 90% of the malignant cells in all cases examined (Figure 1). The Reed–Sternberg and Hodgkin's cells in most mixed cellularity Hodgkin's lymphoma cases (77%) showed a weak to moderate nuclear staining, while only 50% of nodular sclerosis Hodgkin's lymphoma expressed the Pax-5 (Figure 1). All cases of anaplastic large cell lymphoma and precursor T-cell acute lymphoblastic lymphoma were Pax-5-negative (Figure 3).

Figure 1
figure 1

Immunohistochemical staining pattern of the transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 in reactive lymphoid hyperplasia (RLH), nodular lymphocyte predominant Hodgkin's lymphoma (NLPHL), mixed cellularity Hodgkin's lymphoma (MCHL), and nodular sclerosis Hodgkin's lymphoma (NSHL). The neoplastic cells in NLPHL are PU.1-positive. In contrast, the neoplastic cells in classical Hodgkin's are PU.1-negative. Original magnification, × 400.

Full size image
Figure 2
figure 2

Immunohistochemical staining pattern of the transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 in follicular lymphoma (FL), diffuse large B-cell lymphoma (DLBCL), mantle cell lymphoma (MCL), and Burkitt lymphoma. All the transcription factors including PU.1 are expressed in the majority of these subtypes of B-lineage non-Hodgkin's lymphomas. Original magnification, × 400.

Full size image
Figure 3
figure 3

Immunohistochemical staining pattern of the transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 in small lymphocytic lymphoma/chronic lymphocytic leukemia (SLL/CLL), nodal marginal zone B-cell lymphoma (MZBCL), anaplastic large cell lymphoma (ALCL), and precursor T-cell acute lymphoblastic leukemia (T-ALL). Similar to NLPHL and B-lineage lymphomas in Figures 1 and 2, all the transcription factors including PU.1 are expressed in both SLL/CLL and MZBCL. In contrast, the neoplastic cells in ALCL are negative for these transcription factors except for the Oct-1. Similar to ALCL, the neoplastic cells in T-ALL are positive for the Oct-1 and negative for the Pax-5, Oct-2, and BOB.1. However, in contrast to ALCL, the neoplastic cells in T-ALL are PU.1-positive. Original magnification, × 400.

Full size image

OCT-1 and OCT-2 expression

A moderate to strong nuclear positivity was found in germinal center cells in tonsil with reactive lymphoid hyperplasia for the Oct-1 and Oct-2 transcription factors. The B-cells in mantle zone and interfollicular regions showed a less intense nuclear staining. In all cases of Oct-1- and Oct-2-positive non-Hodgkin's lymphoma and classical Hodgkin's lymphoma, the intensity of the Oct-2 staining was always higher than that seen with the Oct-1 (Figures 1, 2 and 3). Similar to the Pax-5, the Oct-1 and Oct-2 were more frequently expressed in mixed cellularity than nodular sclerosis type of Hodgkin's lymphoma. The Oct-2 appeared to be more B-lineage restricted and only one case of T-lineage anaplastic large cell lymphoma demonstrated weak nuclear immunoreactivity for this transcription factor. In contrast, the Oct-1 was expressed in seven of nine T-lineage anaplastic large cell lymphoma and 2 T-lineage acute lymphoblastic lymphoma cases, indicating that this transcription factor is not restricted to B-cells (Figure 3). Both Oct-1 and Oct-2 were expressed in neoplastic cells of all 11 cases of nodular lymphocyte predominant Hodgkin's lymphoma with stronger reactivity observed with the Oct-2 (Figure 1).

BOB.1 expression

The BOB.1 was expressed in germinal center cells in tonsil with reactive lymphoid hyperplasia with moderate intensity and was variably expressed in mantle zone and interfollicular cells with a low-intensity pattern. Except for two mantle cell lymphoma cases that did not express the BOB.1, the remaining nine cases, and all B-lineage non-Hodgkin's lymphomas of the nongerminal center phenotype including small lymphocytic lymphoma, and marginal zone B-cell lymphoma expressed the BOB.1 with weak to moderate intensity (Figures 2 and 3). The lymphomas of germinal center origin including follicular lymphoma, Burkitt lymphoma, and germinal center-derived diffuse large b-cell lymphoma universally demonstrated a strong nuclear staining pattern. The BOB.1 was expressed weakly in only a small subset of mixed cellularity (26%) and nodular sclerosis Hodgkin's lymphomas (11%). In contrast to classical Hodgkin's lymphoma, all cases of nodular lymphocyte predominant Hodgkin's lymphoma expressed the BOB.1 with a moderate to strong intensity (Figure 1). All nine anaplastic large cell lymphoma cases were negative for the BOB.1

PU.1 expression

The PU.1 was expressed by germinal center cells in tonsil with reactive lymphoid hyperplasia with moderate intensity and with weaker intensity in mantle zone lymphocytes. The scattered histiocytes in interfollicular areas demonstrated the PU.1 expression with the strongest intensity as expected. All small B-cell neoplasms and nodular lymphocyte predominant Hodgkin's lymphoma cases expressed the PU.1 (Figures 1, 2 and 3) with a particularly stronger intensity in centroblastic cells of the follicular lymphoma cases. In diffuse large B-cell lymphoma cases, the PU.1 was expressed with weak to moderate intensity in only seven of 14 cases. The PU.1-positive cases were more frequent in the centroblastic variant of diffuse large B-cell lymphoma. In contrast, all four cases of CD30-positive anaplastic variant of diffuse large B-cell lymphoma were PU.1-negative. The classical Hodgkin's lymphoma and T-lineage anaplastic large cell lymphoma cases were all negative for the PU.1, while two cases of precursor T-cell acute lymphoblastic lymphoma displayed weak to moderate immunoreactivity (Figures 1 and 3).

Discussion

The differentiation and proliferation of B-cells are controlled by a network of lineage-restricted transcriptional factors. The first step in commitment of pluripotent progenitor cells to the lymphoid lineage cells results in the formation of the common lymphoid progenitors. The transcription factor PU.1 plays an essential role in the development of both lymphoid and myeloid lineages14 by regulating IL-7 receptor or macrophage-colony stimulating factor. Low levels of PU.1 expression upregulate IL-7 receptor expression on common lymphoid progenitor cells, while high levels of PU.1 prevent IL-7 receptor expression.15

IL-7 receptor expressing common lymphoid progenitor cells give rise to all lymphocyte subsets including B-, T-, and natural killer (NK) cells.

The Pax-5 protein also known as B-cell-specific activator protein (BSAP) regulates expression of the downstream transcription factors such as Oct-1, Oct-2 and BOB.1. Both, Oct-1 and Oct-2 bind to the octamer sequence ATGCAAAT located in the immunoglobulin heavy and light chain variable region promoter and the enhancer in the intron between the joining and constant regions.16 The transactivation potential of Oct-1 and Oct-2 is enhanced by interactions with B-cell-specific co-activator BOB.1.17

Prior studies have shown that despite their rearranged immunoglobulin genes, the Reed–Sternberg and Hodgkin's cells in classical Hodgkin's lymphoma fail to express functional immunoglobulin mRNA transcripts. In addition, in a significant proportion of classical Hodgkin's lymphoma, the Reed–Sternberg and Hodgkin's cells lack B-cell-specific antigens.1, 2, 3, 4 The lack of immunoglobulin mRNA transcripts and proteins as well as B-cell specific antigens have been speculated to be due to either crippling mutations of the immunoglobulin genes found in about 25% of cases,2, 5, 6, 7 or downregulation and disruption of the B-cell-specific transcription factors.8, 9, 10 In contrast to classical Hodgkin's lymphoma, the neoplastic cells in non-Hodgkin's lymphomas of B-lineage and nodular lymphocyte predominant Hodgkin's lymphoma express B-cell-specific antigens, immunoglobulin mRNA transcripts and their proteins.1

Analysis of the transcription factors involved in B-cell differentiation is useful in understanding of the differentiation-linked phenotype in non-Hodgkin's and Hodgkin's lymphomas. The expression profile of transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 is thought to correlate with the lineage and/or the stage of the lymphoid cell differentiation. To further characterize the association between expression of these transcription factors in Reed–Sternberg and Hodgkin's cells and their lack of immunoglobulin mRNA transcripts and/or B-cell-associated antigens, we analyzed the expression of all these transcription factors in classical Hodgkin's lymphoma as well as in nodular lymphocyte predominant Hodgkin's lymphoma, non-Hodgkin's lymphoma of B-lineage, T-lineage anaplastic large cell lymphoma, and precursor T-cell acute lymphoblastic lymphoma.

The results of our study reveal that the transcription factor Pax-5 is B-lineage restricted and is expressed virtually in all types of mature B-cell non-Hodgkin's lymphoma, nodular lymphocyte predominant Hodgkin's lymphoma, and in approximately 65% of the classical Hodgkin's lymphoma. The Pax-5 is absent in T-cell neoplasms,18 including the nine anaplastic large cell lymphoma and the two precursor T-cell acute lymphoblastic lymphoma cases we studied (Table 1). Our results agree with prior observations reported by most investigators,11, 18, 19, 20, 21 but contradicts to certain extent with Krenacs et al19 results who reported a lower rate of expression of the Pax-5 in some subtypes of B-cell lymphomas. The discrepancy may be attributed to the use of polyclonal antibodies in their study, while the other studies including the current one used a monoclonal antibody thought to be more sensitive in detecting the Pax-5 in paraffin-embedded tissue sections.

Similar to the Pax-5, the transcription factors Oct-1 and Oct-2, and BOB.1 were expressed in virtually all B-lineage non-Hodgkin's lymphoma and nodular lymphocyte predominant Hodgkin's lymphoma as well as a variable numbers of classical Hodgkin's lymphoma cases (67, 74, and 19% respectively). In addition, the transcription factor Oct-1 was also detected in two precursor T-cell acute lymphoblastic lymphoma and seven of nine anaplastic large cell lymphoma cases indicating that the Oct-1 is not lineage specific. Expression of the Oct-1 in T-lineage lymphoid neoplasms has been reported by others as well.22, 23 The expression of the Oct-1 in both B- and T-cell derived lymphomas makes this marker less useful in the differential diagnosis of these entities. The T-lineage cases in this study were all negative for BOB.1 and Oct-2 except in one anaplastic large cell lymphoma case that weakly expressed Oct-2.

The transcription factor PU.1 was universally expressed in all neoplastic cells of nodular lymphocyte predominant Hodgkin's lymphoma, follicular lymphoma, mantle cell lymphoma, small lymphocytic lymphoma, and marginal zone B-cell lymphoma cases studied. The PU.1 was also detected in seven of 14 cases of diffuse large B-cell lymphoma. The T-lineage anaplastic large cell lymphoma cases were all negative for this transcription factor. However, the PU.1 was expressed in the two precursor T-cell acute lymphoblastic lymphoma cases studied. The PU.1 was not detected in any of the classical Hodgkin's lymphoma cases (0/40).

In summary, we analyzed expression of transcription factors Pax-5, Oct-1, Oct-2, BOB.1, and PU.1 in B-lineage non-Hodgkin's lymphoma, classical Hodgkin's lymphoma, nodular lymphocyte predominant Hodgkin's lymphoma, anaplastic large cell lymphoma, and precursor T-cell acute lymphoblastic lymphoma. These transcription factors play crucial role in B-cell development and differentiation, as well as in maintenance of B-cell identity. Based on our results and others,11, 17, 18 it appears that expression of the Pax-5 is limited to B-cell lymphomas including subset of CHL with a relatively high sensitivity. The Pax-5 can separate classical Hodgkin's lymphoma from Hodgkin-like anaplastic large cell lymphoma because none of the nine anaplastic large cell lymphoma cases in our study expressed the Pax-5 whereas 26 of 40 classical Hodgkin's lymphoma cases were Pax-5-positive. This observation supports the algorithmic approach proposed by Browne et al, including the utility of the Pax-5 antibody in separating anaplastic large cell lymphoma from classical Hodgkin's lymphoma.11 Also, the Pax-5 can establish the B-cell lineage of rare cases of CD20-negative immunoblastic variant of diffuse large B-cell lymphoma, including those that arise in the setting of human immunodeficiency virus (authors' observation). Therefore, the inclusion of the Pax-5 antibody in the panel of routinely used antibodies may prove useful as an additional marker for assessment of the lineage. We also find that the transcription factor PU.1 is a useful marker in differentiating classical Hodgkin's lymphoma from nodular lymphocyte predominant Hodgkin's lymphoma in problematic cases because all 11 nodular lymphocyte predominant Hodgkin's lymphoma cases in this study expressed PU.1 whereas none of 40 cases of classical Hodgkin's lymphoma were positive for this marker.
