Abstract
Cavity exciton-polaritons1,2 (polaritons) are bosonic quasi-particles offering a unique solid-state system for investigating interacting condensates3,4,5,6,7,8,9,10. Up to now, disorder-induced localization and short lifetimes4,6,11 have prevented the establishment of long-range off-diagonal order12 needed for any quantum manipulation of the condensate wavefunction. In this work, using a wire microcavity with polariton lifetimes much longer than in previous samples, we show that polariton condensates can propagate over macroscopic distances outside the excitation area, while preserving their spontaneous spatial coherence. An extended condensate wavefunction builds up with a degree of spatial coherence larger than 50% over distances 50 times the polariton de Broglie wavelength. The expansion of the condensate is shown to be governed by the repulsive potential induced by photogenerated excitons within the excitation area. The control of this local potential offers a new and versatile method to manipulate extended polariton condensates. As an illustration, we demonstrate synchronization of extended condensates by controlled tunnel coupling13,14 and localization of condensates in a trap with optically controlled dimensions.
This is a preview of subscription content, access via your institution
Access options
Subscribe to this journal
Receive 12 print issues and online access
$259.00 per year
only $21.58 per issue
Buy this article
- Purchase on SpringerLink
- Instant access to the full article PDF.
USD 39.95
Prices may be subject to local taxes which are calculated during checkout
Similar content being viewed by others
References
Weisbuch, C. et al. Observation of the coupled exciton–photon mode splitting in a semiconductor quantum microcavity. Phys. Rev. Lett. 69, 3314–3317 (1992).
Kavokin, A., Baumberg, J. J., Malpuech, G. & Laussy, F. P. Microcavities (Oxford Univ. Press, 2007).
Deng, H. et al. Condensation of semiconductor microcavity exciton polaritons. Science 298, 199–202 (2002).
Kasprzak, J. et al. Bose–Einstein condensation of exciton polaritons. Nature 443, 409–414 (2006).
Balili, R. et al. Bose Einstein condensation of microcavity polaritons in trap. Science 316, 1007–1010 (2007).
Lai, C. W. et al. Coherent zero-state and π-state in an exciton–polariton condensate array. Nature 450, 529–532 (2007).
Bajoni, D. et al. Polariton laser using single micropillar GaAs–GaAlAs semiconductor cavities. Phys. Rev. Lett. 100, 047401 (2008).
Christopoulos, C. et al. Room-temperature polariton lasing in semiconductor microcavities. Phys. Rev. Lett. 98, 126405 (2007).
Christmann, G. et al. Room temperature polariton lasing in a GaN/AlGaN multiple quantum well microcavity. Appl. Phys. Lett. 93, 051102 (2008).
Wertz, E. et al. Spontaneous formation of a polariton condensate in a planar GaAs microcavity. Appl. Phys. Lett. 95, 051108 (2009).
Deng, H. et al. Spatial coherence of polaritons condensates. Phys. Rev. Lett. 99, 126403 (2007).
Penrose, O. & Onsager, L. Bose Einstein condensation and liquid Helium. Phys. Rev. 104, 576–584 (1954).
Baas, A. et al. Synchronized and desynchronized phases of exciton-polariton condensates in the presence of disorder. Phys. Rev. Lett. 100, 170401 (2008).
Wouters, M. Synchronized and desynchronized phases of coupled nonequilibrium exciton-polariton condensates. Phys. Rev. B 77, 121302(R) (2008).
Lagoudakis, K. G. et al. Quantized vortices in an exciton–polariton condensate. Nature Phys. 4, 706–710 (2008).
Lagoudakis, K. G. et al. Observation of half-quantum vortices in an exciton-polariton condensate. Science 326, 974–976 (2009).
Usonomiya, S. et al. Observation of Bogoliubov excitations in exciton-polaritons condensates. Nature Phys. 4, 700–705 (2008).
Amo, A. et al. Collective fluid dynamics of a polariton condensate in a semiconductor microcavity. Nature 457, 291–295 (2009).
Amo, A. et al. Superfluidity of polaritons in semiconductor microcavities. Nature Phys. 5, 805–810 (2009).
Kavokin, A., Malpuech, G. & Laussy, F. P. Polariton laser and polariton superfluidity in microcavities. Phys. Lett. A 306, 187–199 (2003).
Keeling, J. et al. Polariton condensation with localized excitons and propagating photons. Phys. Rev. Lett. 93, 226403 (2004).
Liew, T. C. H., Kavokin, A. V. & Shelykh, I. A. Optical circuits based on polariton neurons in semiconductor microcavities. Phys. Rev. Lett. 101, 016402 (2008).
Shelykh, I. A., Pavlovic, G., Solnyshkov, D. D. & Malpuech, G. Proposal for a mesoscopic optical Berry-phase interferometer. Phys. Rev. Lett. 102, 046407 (2009).
Krizhanovskii, D. N. et al. Coexisting nonequilibrium condensates with long-range spatial coherence in semiconductor microcavities. Phys. Rev. B 80, 045317 (2009).
Dasbach, G. et al. Tailoring the polariton dispersion by optical confinement: Access to a manifold of elastic polariton pair scattering channels. Phys. Rev. B 66, 201201(R) (2002).
Wouters, M., Carusotto, I. & Ciuti, C. Spatial and spectral shape of inhomogeneous nonequilibrium exciton-polariton condensates. Phys. Rev. B 77, 115340 (2008).
Dubin, F. et al. Macroscopic coherence of a single exciton state in an organic quantum wire. Nature Phys. 2, 32–35 (2005).
Idrissi Kaitouni, R. et al. Engineering the spatial confinement of exciton polaritons in semiconductors. Phys. Rev. B 74, 155311 (2006).
Sanvitto, D. et al. Exciton-polariton condensation in a natural two-dimensional trap. Phys. Rev. B 80, 045301 (2009).
Acknowledgements
This work was partly supported by the C’Nano Ile de France contract ‘Sophiie2’, by the ANR contract PNANO- 07-005 GEMINI, by the FP7 ITN ‘Clermont4’ (235114) and by the FP7 ITN ‘Spin-Optronics’ (237252).
Author information
Authors and Affiliations
Contributions
E.W., L.F. and J.B. carried out the experiments and analysed the data. D.D.S., R.J., A.V.K. and G.M. theoretically studied the data. D.S. participated in some experiments. A.L. grew the sample, I.S. etched the microwires and R.G. gave fruitful advice for the Young slit experiments. P.S. did the electron-beam lithography, interpreted the data and wrote the paper. J.B. supervised the work and wrote the paper.
Corresponding author
Ethics declarations
Competing interests
The authors declare no competing financial interests.
Supplementary information
Supplementary Information
Supplementary Information (PDF 529 kb)
Rights and permissions
About this article
Cite this article
Wertz, E., Ferrier, L., Solnyshkov, D. et al. Spontaneous formation and optical manipulation of extended polariton condensates. Nature Phys 6, 860–864 (2010). https://doi.org/10.1038/nphys1750
Received:
Accepted:
Published:
Issue date:
DOI: https://doi.org/10.1038/nphys1750
