Fig. 8: 3D quasicrystals fabricated with ImpFab.
From: Three-dimensional nanophotonics with spatially modulated optical properties
Reconstructed 3D icosahedral quasicrystal. The left and right panel shows fluorescence projection images for twofold- and fivefold-symmetric axes, respectively. Scale bars are 50 μm
