Fig. 1: Overview of DropLab. | Microsystems & Nanoengineering

Fig. 1: Overview of DropLab.

From: DropLab: an automated magnetic digital microfluidic platform for sample-to-answer point-of-care testing—development and application to quantitative immunodiagnostics

Fig. 1

a The internal mechanisms of the DropLab platform assembled view ai, including the magnetic droplet manipulation module, the optical module, and the one-fits-all adapter with the DropLab chip loaded aii. b Picture of the DropLab platform. c Workflow of performing POCT immunodiagnostics with DropLab
