Fig. 2: Acoustofluidic sorting of DENV and TBEV.
From: Multiple virus sorting based on aptamer-modified microspheres in a TSAW device
a Structure and image of the TSAW device. b The sorting outlets when SAW switched off/on (15 μm PS microspheres in green circles and 2 μm PS microspheres in red circles). c The purity of the 15 μm PS microspheres and 2 μm PS microspheres at the inlet, outlet 1 and outlet 2. d The relative genetic expression of the virus on the sorted microspheres
