Fig. 5

SEM images of (a) the final product of the AFM probe with 120 µm cantilever after oxidation sharpening, and b–d the enlarged view of the cantilever and the tip. All images were captured using a JOEL JSM-7200F SEM with the samples mounted on a 90° tilted stage
