Fig. 4 | Nature Communications

Fig. 4

From: Non-saturating quantum magnetization in Weyl semimetal TaAs

Fig. 4The alternative text for this image may have been generated using AI.

Comparison between experiments and theory for the M|| and MT of TaAs. a M|| (black line) and b MT (black line). The blue dashed lines represent the theoretical results with the constraint of the fixed EF in the full range of magnetic field, while the red dashed lines represent the results with the constraint of the fixed Nc in strong fields
