Fig. 4: Reactive Fe-bound organic carbon along the permafrost thaw gradient.

Iron (Fe) and carbon (C) associations were determined along the thaw gradient by bulk (b) and fine fraction analysis (a). a Carbon bound by reactive iron minerals along the thaw gradient. The carbon which dislodged from the soil during the reductive dissolution of reactive iron oxides (orange) is shown in comparison to the total organic carbon determined via combustion (black grids, labeled as total organic carbon (TOC)). Dithionite–citrate extractable carbon is control-corrected by subtracting the measured dissolved organic carbon (DOC) content of a citrate solution and the measured DOC value from the sodium chloride (NaCl) control experiment. The NaCl control (same ionic strength and same pH as the sodium dithionite citrate extraction) shows negligible carbon release (Supplementary Table 1). Errors of the TOC indicate the range of duplicate analyses of each layer in each thaw stage. Errors of the dithionite/citrate extractable carbon (control corrected) represent a combined standard deviation of sodium chloride bicarbonate extractable OC, citrate blank, and dithionite/citrate extractable OC (not control corrected). b High spatial resolution analysis of iron–carbon associations by nanoSIMS along the thaw gradient (two end-members palsa (left) and fen (right)). The strong spatial association of carbon to iron (III) minerals could only be observed in the palsa transition zone. The other fine fractions showed organic-free iron minerals. For the two end-members palsa and fen, four particles of the fine fractions of each layer were analyzed by nanoSIMS, all showing the same spatial distribution of Fe and C as shown by these six representatives (see also Supplementary Fig. 11). The green background marks the organic horizon (b, upper images), gray the transition zone (b, middle images), and yellow the mineral horizon (b, lower images).
