Fig. 8: COVA1-27 tracer uptake in the kidneys.

From: Whole-body visualization of SARS-CoV-2 biodistribution in vivo by immunoPET imaging in non-human primates

Fig. 8: COVA1-27 tracer uptake in the kidneys.The alternative text for this image may have been generated using AI.

Representative PET signal in the kidneys of CM4 (a), CM8 (b), and CM7 (c), color scale 0–4 SUV. d Longitudinal evaluation of the PET signal SUVmean normalized against that of 0 dpe in the kidneys of animals and e quantification of the mean [89Zr]COVA1-27-DFO PET signal normalized to that of 0 dpe in the kidneys. The exposed + COVA group is indicated in turquoise (circles, squares, hexagons, diamonds, n = 4), the exposed + IgG group in pink (circles, squares, n = 2), and the mock + COVA group in black (triangles, n = 2). Data are presented as individual values the the mean and SD. Source data are provided as a Source data file.
