Fig. 4: Application of printed G-CAPode in logic gate circuits.

From: Redox-active electrolyte-based printed ionologic devices

Fig. 4: Application of printed G-CAPode in logic gate circuits.

a Schematic of the electroadsorption-based switching mechanism (blue ball: H3O+ ions; green ball: PW12O403− ions). b Monolithic ipG-CAPode architecture. c Electrical circuit diagram. d I–U curves in on/off-state with RR sequence (inset plot). e NOT logic circuit scheme. Input and output signals for f commercial transistor and g ipG-CAPode.
