Fig. 1: Representative lithic clasts in CE-6 soil for sulfur isotope analyses.
From: Sulfur isotopes from the lunar farside reveal global volatile loss following the giant impact
Large clasts of mare basalts (a, b), noritic anorthosite (c), norite (d) and breccia (e, f) are shown. Orange circles (~8 µm in diameter) mark laser ablation spots for sulfur isotope analyses, with corresponding δ³⁴S values labeled. The Mg# of clinopyroxene (Cpx) and orthopyroxene (Opx) closely associated with troilites and An# of plagioclase in anorthositic norite are also indicated. Tro troilite, Pl plagioclase, Cpx clinopyroxene, Opx orthopyroxene, Ap apatite, Ilm ilmenite.
