Fig. 5: Intracellular killing of Neisseria gonorrhoeae in cultured HeLa229 human cervix carcinoma cells.

From: The bactericidal FabI inhibitor Debio 1453 clears antibiotic-resistant Neisseria gonorrhoeae infection in vivo

Fig. 5: Intracellular killing of Neisseria gonorrhoeae in cultured HeLa229 human cervix carcinoma cells.

a Intracellular killing of N. gonorrhoeae strain ATCC 49226 at increasing multiples of Debio 1453 or azithromycin minimum inhibitory concentration (MIC). b Intracellular killing of N. gonorrhoeae strain WHO X at increasing multiples of Debio 1453 or azithromycin MIC. Data are the mean of biological triplicates +/− standard deviation. Dotted grey lines indicate the limit of detection. CFU colony forming unit, CIP-R ciprofloxacin-resistant, CRO-R ceftriaxone-resistant. Source data are provided as a Source Data file.
