Fig. 5: Seawater splitting performance of LDH-Ti/HCC.

From: Oxide-hybridized carbon as a catalyst support for efficient anion exchange membrane water electrolysis

Fig. 5

a LSV curve for OER of LDH-HCC and LDH-Tixwt%/HCC (inset: overpotential at 10 mA cm-2). b Long-term durability test via chronopotentiometry conditions for 0.1 A cm-2 in a half-cell setup. c I−V curves for AEMWE operated under 1 M KOH + 0.5 M NaCl condition (pH 14). d AEMWE durability test in 1 M KOH + 0.5 M NaCl at 1 A cm-2. e I-V curves and f durability test result for AEMWE operated under 1 M KOH + seawater (pH 13.8) conditions. Source data are provided as a Source Data file.
