Extended Data Fig. 3: CLE45 treatments do not affect the SHR pathway.
From: Antagonistic CLE peptide pathways shape root meristem tissue patterning
a, Confocal microscopy images of Col-0 wildtype root meristems grown on 20 nM CLE45 peptide in the absence or presence of ZIC2 (25 mM). b, Confocal microscopy images of Col-0 root meristems expressing the CVP2::NLS-VENUS protophloem sieve element marker, grown on ZIC2 (25 mM) as compared to control. c, Confocal microscopy images of Col-0 root meristems (propidium iodide staining, red fluorescence) expressing various markers of the SHR pathway (green fluorescence), grown on 15 nM CLE45 peptide as compared to controls. Seedlings were 5-day-old throughout.
