Fig. 2: High-fold degenerate TSM representatives. | npj Computational Materials

Fig. 2: High-fold degenerate TSM representatives.

From: Exhaustive screening of high-fold degenerate topological semimetal with chiral structure

Fig. 2

Band structures of (a) Ba2Ir3O9 (space group No. 197) with two fourfold degenerate points, (b) Mg3Ru2 (space group No. 213) with two fourfold degenerate points and one threefold degenerate point, (c) LiBi3O6 (space group No. 199) with one fourfold degenerate point and one sixfold degenerate point, and d La3SiBr3 (space group No. 214) with one fourfold degenerate point and one threefold degenerate point.
