Extended Data Fig. 7
Proportional change in predicted dispersal distance with a 10% increase in the probability that a larva is planktotrophic (Panel a), a 10% increase in egg size (in log-scale) (Panel b), a 10% increase in the effect of temperature on planktonic duration (with absolute latitude as a proxy) (Panel c), and a 10% increase in mean annual surface speed (Panel d). White colour indicates areas where the proportional change in the predicted dispersal distance is equal to the proportional change in the dispersal driver of interest, blue colours show areas it is larger (that is a 10% increase in the driver of interest results in a > 10% increase in predicted dispersal distance), and red colours show areas where it is smaller (that is a 10% increase in the driver of interest results in a < 10% increase in predicted dispersal distance). Panel d used data from surface drifters74.
