Extended Data Fig. 3: Source of the material at the landing site.
From: Chandrayaan-3 APXS elemental abundance measurements at lunar high latitude
a, Kaguya TC orthoimage showing the region around the landing site (marked by the solid yellow circle). The chains and clusters of secondaries (classes 1 and 2) are marked in the figure. Solid white lines represent the boundary of the ‘Ntp’ geological unit (intercrater plains region). b, False-colour composite image of band ratios from Clementine UVVIS134. The colours correspond to band ratios of 750 nm/415 nm (red), 750 nm/950 nm (green) and 415 nm/750 nm (blue). In the figure, mature lunar highlands appear in shades of red and the bright blue shades represent rays of a young crater135,136. Arrows mark the ejecta rays from the Schomberger crater extending towards the landing site.
