Extended Data Fig. 6: HA-PCSPVY-aNLR failed to confer resistance against TEV.

From: Remodelling autoactive NLRs for broad-spectrum immunity in plants

Extended Data Fig. 6: HA-PCSPVY-aNLR failed to confer resistance against TEV.The alternative text for this image may have been generated using AI.

a, Co-expression of HA-PCSPVY-aNLR with PVY NIa-Myc, but not TEV NIa-Myc, caused cell death. Photograph was taken at 3 days post agroinfiltration. b, TEV-GFP spread over WT and T1 transgenic HA-PCSPVY-aAtNRG1.1 plants of line 1 at 7 dpi. c, RT-PCR detected the presence of TEV RNA in WT and transgenic HA-PCSPVY-aAtNRG1.1 plants at 7 dpi by TEV-GFP. Experiments were repeated at least three times with similar results.
