Extended Data Fig. 8: Spatially resolved transcriptomic atlas of mouse organogenesis.

Related to Fig. 4. a. Spatial visualization of the captured gene counts across sections from E17.5, P0 and P4 mice. b. Spatial visualization of tissue-specific marker genes across sections from E17.5, P0 and P4 mice. c. Dot plot showing the expression levels of the differentially expressed genes in the developing cerebellum. d. RNA velocity streamline plot (left) and pseudotime trajectory analysis (right and middle, respectively) of the cerebellums from E17.5, P0 and P4 mice. Spots are colored by the developmental stages (left), cerebellum regions (middle) or pseudotime (right). e. Spatial visualization of the dynamically changed genes across E17.5, P0 and P4 cerebellums. Exp., expression.
