Extended Data Fig. 7: Spatially compartmentalized diversification of intestinal eosinophils.
From: Temporal and spatial atlas of eosinophil specialization across tissues
a, Representative immunofluorescence image of eosinophils on Ms4a3CreERT2-Rosa26tdTomato lung slides. Scale bar=20μm. b, Representative immunofluorescence image of colocalization of blood vessels with eosinophils on wild-type (WT) lung slides. Scale bar=10μm. c, Schematic diagram of intestinal segment selection for analysis. Scale bar=500μm (colon). Scale bar=1 mm (SI). d, Representative immunofluorescence images of CD22 staining in different intestinal segments 3 weeks post-tamoxifen induction on Ms4a3CreERT2-Rosa26tdTomato intestine slides. Representative of 5 independent experiments. Scale bar=20μm. Duode, duodenum; Jeju, jejunum; Ile, ileum; Proxi-Colon, proximal colon; Dis-colon, distal colon.
