Fig. 16

Dislocation defect surface of the material after uniaxial stretching: (a₁,b₁) are without BN particles, (a₂,b₂) are with the 2% nanoparticles. Images were displayed by OVITO Basic (www.ovito.org) to calculate the modeled defective surfaces and exported, then assembled by PowerPoint.
