Fig. 10
From: Graphene oxide and cannabidiol-based hybrid coatings on PMMA for biomedical applications
Wear scar micrographs of samples subjected to 5 N of load: (a) SG3, Fn = 5 N, (b) SG9.5, Fn = 5 N, (c) SG3/GO, Fn = 5 N, (d) SG9.5/GO, Fn = 5 N, (e) SG3/CBD/GO, Fn = 5 N, (f) SG9.5/CBD/GO, Fn = 5 N.
