Fig. 8

From: Efficient target detection method based on wavelet transform and progressive feature pyramid network: a case study of power grid inspection

Fig. 8

Qualitative detection results of the proposed model on the TLFO test set. The three examples (a–d) cover different transmission-line scenes and foreign-object types (nests, kites, balloons, trash). Coloured bounding boxes denote the four target categories, illustrating that the detector can localise small, low-contrast objects in the presence of complex background structures.
