Fig. 4: Changes in the ENSO growth rate and its five contributing terms (see “Methods”) averaged from June to November. | npj Climate and Atmospheric Science

Fig. 4: Changes in the ENSO growth rate and its five contributing terms (see “Methods”) averaged from June to November.

From: Projected Antarctic sea ice change contributes to increased occurrence of strong El Niño

Fig. 4

MA, TD, ZA, TH, and EK (1/year) represent mean currents damping, thermodynamic damping, zonal advective feedback, thermocline feedback, Ekman (upwelling) feedback, respectively. BJ (1/year) is the sum of these five terms. Red bars are ANTSIlate21 minus ANTSIhist, and blue bars are ANTSI4CO2 minus ANTSIhist.
