Abstract
Neuromorphic hardware that accurately simulates diverse neuronal behaviours could be of use in the development of edge intelligence. Hardware that incorporates synaptic plasticity—adaptive changes that strengthen or weaken synaptic connections—has been explored, but mimicking the full spectrum of learning and memory processes requires the interplay of multiple plasticity mechanisms including intrinsic plasticity. Here we show that an integrate-and-fire neuron can be created by combining a dynamic random-access memory and an inverter that are based on wafer-scale monolayer molybdenum disulfide films. In the system, the voltage in the dynamic random-access memory capacitor—that is, the neuronal membrane potential—can be modulated to emulate intrinsic plasticity. The module can also emulate the photopic and scotopic adaptation of the human visual system by dynamically adjusting its light sensitivity. We fabricate a 3 × 3 photoreceptor neuron array and demonstrate light coding and visual adaptation. We also use the neuron module to simulate a bioinspired neural network model for image recognition.
This is a preview of subscription content, access via your institution
Access options
Similar content being viewed by others
Data availability
The source data file is available via figshare at https://figshare.com/s/a8fa70a5665cab68512d. Source data are provided with this paper.
Code availability
The codes used for simulation and data plotting are available from the corresponding authors upon reasonable request.
References
Wong, T. M. et al. 1014. Report No. RJ10502(ALM1211-004) (IBM, 2012).
Cox, DavidD. & Dean, T. Neural networks and neuroscience-inspired computer vision. Curr. Biol. 24, R921–R929 (2014).
Mehonic, A. & Kenyon, A. J. Brain-inspired computing needs a master plan. Nature 604, 255–260 (2022).
Roy, K., Jaiswal, A. & Panda, P. Towards spike-based machine intelligence with neuromorphic computing. Nature 575, 607–617 (2019).
Indiveri, G. et al. Neuromorphic silicon neuron circuits. Front. Neurosci. 5, 73 (2011).
Chen, J. et al. Mimicking neuroplasticity via ion migration in van der waals layered copper indium thiophosphate. Adv. Mater. 34, 2104676 (2022).
Wang, Z. Q. et al. Synaptic learning and memory functions achieved using oxygen ion migration/diffusion in an amorphous InGaZnO memristor. Adv. Funct. Mater. 22, 2759–2765 (2012).
Zhang, Z. et al. Truly concomitant and independently expressed short- and long-term plasticity in a Bi2O2Se-based three-terminal memristor. Adv. Mater. 31, 1805769 (2019).
Zhu, J. et al. Ion gated synaptic transistors based on 2D van der waals crystals with tunable diffusive dynamics. Adv. Mater. 30, 1800195 (2018).
Sung, S. H., Kim, T. J., Shin, H., Im, T. H. & Lee, K. J. Simultaneous emulation of synaptic and intrinsic plasticity using a memristive synapse. Nat. Commun. 13, 2811 (2022).
Debanne, D., Inglebert, Y. & Russier, M. Plasticity of intrinsic neuronal excitability. Curr. Opin. Neurobiol. 54, 73–82 (2019).
Kourrich, S., Calu, D. J. & Bonci, A. Intrinsic plasticity: an emerging player in addiction. Nat. Rev. Neurosci. 16, 173–184 (2015).
Mozzachiodi, R. & Byrne, J. H. More than synaptic plasticity: role of nonsynaptic plasticity in learning and memory. Trends Neurosci. 33, 17–26 (2010).
Zhang, W. & Linden, D. J. The other side of the engram: experience-driven changes in neuronal intrinsic excitability. Nat. Rev. Neurosci. 4, 885–900 (2003).
Dalgaty, T. et al. Hybrid CMOS-RRAM neurons with intrinsic plasticity. In 2019 IEEE International Symposium on Circuits and Systems (ISCAS) 1–5 (IEEE 2019).
Baek, E. et al. Intrinsic plasticity of silicon nanowire neurotransistors for dynamic memory and learning functions. Nat. Electron. 3, 398–408 (2020).
Wu, L. et al. Implementation of neuronal intrinsic plasticity by oscillatory device in spiking neural network. IEEE Trans. Electron Devices 69, 1830–1834 (2022).
Xia, Y. et al. 12-inch growth of uniform MoS2 monolayer for integrated circuit manufacture. Nat. Mater. 22, 1324–1331 (2023).
Li, T. et al. Epitaxial growth of wafer-scale molybdenum disulfide semiconductor single crystals on sapphire. Nat. Nanotechnol. 16, 1201–1207 (2021).
Lemme, M. C. & Daus, A. Low-temperature MoS2 growth on CMOS wafers. Nat. Nanotechnol. 18, 446–447 (2023).
Chen, X. et al. Wafer-scale functional circuits based on two dimensional semiconductors with fabrication optimized by machine learning. Nat. Commun. 12, 5953 (2021).
Ma, S. et al. An artificial neural network chip based on two-dimensional semiconductor. Sci. Bull. 67, 270–277 (2022).
Wang, X. et al. Pass-transistor logic circuits based on wafer-scale 2D semiconductors. Adv. Mater. 34, 2202472 (2022).
Ning, H. et al. An in-memory computing architecture based on a duplex two-dimensional material structure for in situ machine learning. Nat. Nanotechnol. 18, 493 (2023).
Ma, J. et al. Engineering top gate stack for wafer-scale integrated circuit fabrication based on two-dimensional semiconductors. ACS Appl. Mater. Interfaces 14, 11610–11618 (2022).
Tang, J. et al. Low power flexible monolayer MoS2 integrated circuits. Nat. Commun. 14, 3633 (2023).
Liao, F. et al. Bioinspired in-sensor visual adaptation for accurate perception. Nat. Electron. 5, 84–91 (2022).
Miller, R. E. & Tredici, T. J. Night Vision Manual for the Flight Surgeon. Report No. AL-SR-1992-0002 (Armstrong Lab Brooks AFB TX, 1992).
Kolb, H., Fernandez, E. & Nelson, R. Webvision: The Organization of the Retina and Visual System (Univ. Utah Health Sciences Center, 1995).
Tang, J. et al. Bridging biological and artificial neural networks with emerging neuromorphic devices: fundamentals, progress, and challenges. Adv. Mater. 31, 1902761 (2019).
Burkitt, A. N. A review of the integrate-and-fire neuron model: I. Homogeneous synaptic input. Biol. Cybern. 95, 1–19 (2006).
Zhou, J., Benson, N. C., Kay, K. N. & Winawer, J. Compressive temporal summation in human visual cortex. J. Neurosci. 38, 691 (2018).
Li, Y. et al. Oxide-based electrolyte-gated transistors for spatiotemporal information processing. Adv. Mater. 32, e2003018 (2020).
Purves, D. et al. Neuroscience (Sinauer Associates, 2004).
Rueckauer, B. & Liu, S. C. Conversion of analog to spiking neural networks using sparse temporal coding. In 2018 IEEE International Symposium on Circuits and Systems (ISCAS) 1–5 (IEEE, 2018).
Zhai, Y. et al. 2D heterostructure for high-order spatiotemporal information processing. Adv. Funct. Mater. 32, 2108440 (2021).
Feldman, D. E. The spike-timing dependence of plasticity. Neuron 75, 556–571 (2012).
Duan, Q. et al. Spiking neurons with spatiotemporal dynamics and gain modulation for monolithically integrated memristive neural networks. Nat. Commun. 11, 3399 (2020).
Acknowledgements
We thank the support for device fabrication at the Guangzhou Innovation Centre of Optoelectronics and Microelectronics (GICOM). W.B. acknowledges support from the National Key Research and Development Program (grant no. 2021YFA1200500), Science and Technology Commission of Shanghai Municipality (no. 23JC1401100) and the Shanghai Pilot Program for Basic Research—Fudan University 21TQ1400100 (23TQ008). Y.C. thanks MOST National Key Technologies R&D Program (2022YFA1203804) and National Natural Science Foundation of China (62425405). W.B. and P.Z. also acknowledge support from the young scientist project of MOE innovation platform.
Author information
Authors and Affiliations
Contributions
Y.W., Y.C., P.Z. and W.B. conceived and supervised the project. S.G. introduced the concept of intrinsic plasticity. S.G., X.D., X.G., L.T. and J.M. fabricated the device. Y.W. and X.D. performed the BioNN simulation. Y.W., S.G., X.C., X.W. and Q.S. performed the electrical measurement. All authors discussed the results and contributed to the manuscript preparation.
Corresponding authors
Ethics declarations
Competing interests
The authors declare no competing interests.
Peer review
Peer review information
Nature Electronics thanks the anonymous reviewers for their contribution to the peer review of this work.
Additional information
Publisher’s note Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Supplementary information
Supplementary Information (download PDF )
Supplementary Note 1, Figs. 1–32, and Tables 1 and 2.
Supplementary Video 1 (download MP4 )
The evolution of the output spike during the learning process.
Supplementary Video 2 (download MP4 )
The evolution of VW during the learning process.
Source data
Source Data Fig. 1 (download XLSX )
Statistical source data.
Source Data Fig. 2 (download XLSX )
Statistical source data.
Source Data Fig. 3 (download XLSX )
Statistical source data.
Source Data Fig. 4 (download XLSX )
Statistical source data.
Source Data Fig. 5 (download XLSX )
Statistical source data.
Rights and permissions
Springer Nature or its licensor (e.g. a society or other partner) holds exclusive rights to this article under a publishing agreement with the author(s) or other rightsholder(s); author self-archiving of the accepted manuscript version of this article is solely governed by the terms of such publishing agreement and applicable law.
About this article
Cite this article
Wang, Y., Gou, S., Dong, X. et al. A biologically inspired artificial neuron with intrinsic plasticity based on monolayer molybdenum disulfide. Nat Electron 8, 680–688 (2025). https://doi.org/10.1038/s41928-025-01433-y
Received:
Accepted:
Published:
Version of record:
Issue date:
DOI: https://doi.org/10.1038/s41928-025-01433-y
