Fig. 5: Brain cellular co-localization was performed with GFP and respective co-stains. | Communications Biology

Fig. 5: Brain cellular co-localization was performed with GFP and respective co-stains.

From: Cellular trafficking and fate mapping of cells within the nervous system after in utero hematopoietic cell transplantation

Fig. 5

a Iba-1-positive microglial cell within the distal brain stem; b highly engrafted Iba-1-positive meningeal macrophages; c GFAP-positive possible radial glial cell; d GFAP-positive astrocytes adjacent to a blood vessel with nearby glial appearing cell right inferiolateral plane; e, f multiple calbindin-positive Purkinje neurons with both cell body and dendritic trees; g ×40 magnification of engrafted neuron demonstrates co-staining with Neu-N-positive neurons; h ×20 magnification shows several of the previously demonstrated round undifferentiated cells as SOX-2-positive progenitor cells.
