Fig. 2: Experimental setup.
From: Clay alignment takes place during early stages of sedimentation
a Sketch of sedimentation column; (b) sedimentation column mounted in experimental hutch at ESRF ID22; (c) final sediment sample after experiment, crack resulted from column unmounting; (d) single 2D diffraction image with (00 l) diffraction rings of kaolinite indicated.
