Fig. 4: Electrochemical performance evaluation of ASSLMBs at 303 K.

From: Harnessing database-supported high-throughput screening for the design of stable interlayers in halide-based all-solid-state batteries

Fig. 4

a Initial galvanostatic charge-discharge profiles comparing Li|In-Li6PS5Cl|Li3InCl6|LiCoO2 and Li|Li3OCl|Li3InCl6|LiCoO2 cells at 1 C rate (1.1 mA cm−2). b Cycling stability and Coulombic efficiency of both cell configurations at 1 C rate over 1000 cycles. c First-cycle voltage profile of Li|Li3OCl|Li3InCl6|Li(Ni0.8Co0.1Mn0.1)O2 cell at 3 C rate (3.8 mA cm−2). d Long-term cycling performance and Coulombic efficiency of the Li|Li3OCl|Li3InCl6|Li(Ni0.8Co0.1Mn0.1)O2-based cell at 3 C rate through 1500 cycles.
